The RAY98 (P) Gun-Style Portable X-Ray Machine provides a practical and advanced solution for dental diagnostic imaging. Its ergonomic gun-shaped design offers comfortable handling, while the long-lasting battery and smart angle adjustment help support accurate image acquisition.
Large Display Screen
Provides clear and easy-to-view information during operation.
Convenient Button Adjustment
Simplifies device control and helps improve diagnostic workflow efficiency.
Extended Handle Design
Designed for a comfortable grip and easier operation.
Recessed Power Button
Helps prevent accidental activation during handling.
Atmospheric & Concise Design
Combines a clean appearance with a practical operating structure.
Smart Angle Adjustment
Allows flexible positioning to help achieve clearer diagnostic images.
| Specification | Details |
|---|---|
| Model | RAY98 (P) |
| Tube Voltage | 70 KV ± 10% |
| Tube Current | 2mA ±20% |
| Charge Input Voltage | 100 V - 240V |
| Frequency | 50Hz-60Hz |
| X-Tube | Canon D-045 |
| Anode Angle | 12.5° |
| Focus | 0.4mm |
| Exposure Time Range | 0.04s - 2.0s |
| Leak Emissivity | 1 meter ≤0.25mGy/h |
| Machine Weight | 1.7kg |
| Relative Humidity | 30%RH~75%RH |
